Ford F350

Custom Fitted E-Radial Hand Control

A custom set of Guidosimplex E-Radial hand controls have been installed into this workhorse.

As Jason regularly drives very long distances it was important that the hand control was located in the optimum position adjacent to the arm rest  on the door to limit shoulder fatigue. Modifications were also required to the column shift so the full range of gears could be achieved without interfering with the hand controls.

Options

Kubota RTV-X900

Push Pat Mechanical Hand controls with custom brake linkage

We Got the job of modifying this awesome Kubota for Tony, fitted with a set of push pat hand controls and custom brake linkage he is now set to hit the paddocks!!

Options

• Push Pat Mechanical Hand Controls
• Custom brake linkage
• Modified handbrake
• Modified gear stick

Ford Mondeo

Modified Mondeo

This 2018 Skoda Ford Mondeo has been fitted with Guidosimplex Electronic radial hand controls mounted right side  (push to brake).

A Custom handle was manufactured for the E radial with bump switch to enable control of the Lodgesons Mini Keypad adapted to  indicators high low beam, horn, wipers.    A  steering aid was installed to the steering wheel.

Leg room was a must so installed the hand controls as high as possible while still achieving full adjustment of the steering column.

The lower sections of both the left and right door trims were modified so the client could gain closer access for transfer.

Vehicle protection was very important, we installed clear paint protection film to the rear right hand door and drivers sill . We also manufactured covers for the left hand front seat, center console lid and drives sill to prevent damage when loading and unloading wheelchair.

Options

• Electronic Radial Hand Controls
• Lodgesons CAN Interface Mini keypad
• Modified door trims for greater assess
• Steering Aid
• Passenger seat protection, console and door trim protection
• Sill protection

Range Rover Sport

Sleek and sophisticated

Electronic Radial hand controls

This prestige Range Rover was bought to us as the client was unimpressed with instillation’s on previous vehicles. We installed a set of Guidosimplex electronic radial hand controls while still maintaining full adjustment of the steering column as this was vital due to height differences between drivers.

All in all the client was very happy with the instillation.

Options

• Electronic radial hand controls
• Fully adjustable steering column after instillation

Toyota Landcruiser

Electronic Radial Hand control Replacement

Our great client Wendy came to us in a very uncomfortable position, her hand controls had been digging into her legs for the past 5 years. Upon inspection we noticed the controls were very low and also removable, which was a requirement when they were installed in New South Wales. The Knee airbag had also been bypassed.

We removed the old hand controls and mounting and airbag disconnect module, manufactured a new mount for the Guidosimplex Electronic radial hand controls and ran the brake rod through the lower panel so it would no longer hinder the operation of the airbag.

Wendy achieved a lot more leg room and a comfortable seated position, problem solved!

Options

• Electronic radial hand controls

Skoda Octavia RS

Electronic hand controls with CAN interface Bleeper system

Contact us for more information on any of the installed products

This 2017 Skoda Octavia RS has been fitted with Guidosimplex Electronic radial hand controls mounted right side  (push to brake).

A Custom handle was manufactured for the E radial with bump switch to enable control of the Lodgesons CAN interface bleeper system adapted to  indicators high low beam, horn, wipers.    A Tri pin steering aid was installed to the steering wheel.

Leg room was a must so we fabricated a Custom foot plate for left side of brake pedal and modified the accelerator pedal to fold up.

A custom gear lever shift devise was manufactured to assist with the operation of the shift release button

Vehicle protection was very important, we installed clear paint protection film to both right hand doors , drivers sill and rear bumper. We also manufactured covers for the left hand front seat, center console lid and drives sill to prevent damage when loading and unloading wheelchair.

Options

• Electronic Radial Hand Controls
• Lodgesons CAN Interface Bleeper  system
• Flip up Accelerator pedal
• Custom Foot Plate
• Tri Pin Steering Aid
• Passenger seat protection, console and door trim protection
• Sill protection

MazdaBT50 GT

A well equipped vehicle designed to go anywhere.

Contact us for more information on any of the installed products

This vehicle was a fantastic challenge, and the end result speaks for itself. This Truck will go wherever it is taken!!

The vehicle was fitted Veigel Push pull hand control with a 5 way switch we integrated to replicate the functions of the left steering column stalk. we also fabricated a custom tunnel mount to make sure we got the control in the clients desired position.

We then installed electric tip up plates to the left and right hand front seating positions, there was limited space between the B pillar and the seat. we worked around the challenges and fabricated some custom mounts for the lifts and also upgraded the motors to increase the weight carrying capacity.

The vehicle then received its modifications on the rear, the factory tub was removed and we installed a Bronco steel ute tray. This provided a great base for the instillation of the Healy Quicklift crane with remote winch we fabricated some custom brackets, mounted all the hydraulic controls to the headboard and wired in a second battery with management system in to the tray to run the crane set up.

We also installed a Camera monitoring system that is affixed to both the Ute cargo area and on the crane boom itself, these additional cameras were integrated into the factory touch screen so the winch and crane could be operated safely from the drivers seat by switching between camera views.

At the clients request we also fitted all the aftermarket accessories he sourced for his vehicle including

• Bullbar and winch
• Snorkel
• Lift kit
• Rock sliders
• Long range fuel tank
• Aftermarket wheels and tyres

Options

• Veigel push pull hand control with integrated switch for wiper and washer operation
• Electric tip up plates to left hand and right hand front seating positions with upgraded motors
• Bronco steel Tray
• Quick lift crane installed to tray with remote hydraulic and winch operation
• Camera monitoring system for crane integrated to factory head unit

Audi RS5

Electronic Radial Hand controls, folding accelerator pedal, clear sill protection

Contact us for more information on any of the installed products

Electronic Radial Hand controls, folding accelerator pedal, clear sill protection

This 2013 Audi RS5 has been fitted with a Guidosimplex electronic hand control that integrates into the vehicles factory fly by wire accelerator control.

These controls have been installed and customized to achieve the maximum amount of leg room under the steering column which gives more leg location options whilee driving and also creates more space for transfer.

The accelerator pedal has also been modified to fold up, creating more foot room for the driver

Options

• Electronic Radial Hand Controls
• Folding Accelerator pedal
• Sill Protection

Holden VE Commodore V8

Light touch was the theme for these adaptions

Contact us for more information on any of the installed products

This Commodore has been fitted with a Guidosimplex electronic hand control that integrates into the vehicles factory fly by wire accelerator control.

These controls have been installed and customized to achieve the maximum amount of leg room under the steering column which gives more leg location options while driving and also creates more space for transfer.

We also installed a remote start kit and electric handbrake so these functions can be performed at the push of a button.

To ease the operation of both the stereo and climate control, an Alpine Touch screen head unit was installed with an integrated touch screen climate control panel.

A custom billet gear shift knob was also fabricated to change the operation of the shifter to a simple push down arrangement

Options

• Electronic Radial hand controls
• Alpine touch screen Head unit with integrated Touch Climate controls
• Remote start kit
• Electric Park brake
• Custom billet Shifter

Honda Jazz

Jazzy little Jazz

Contact us for more information on any of the installed products

This little Honda Jazz was fitted with mechanical Push Pat hand controls mounted to right side of steering column. Billet adaptions were made for both the headlight and wiper switches and also the heater controls to simplify their operation.
A Custom foot plate for left side of brake pedal and modification for fold up accelerator pedal were also required to maximise available leg room.

We also manufactured a billet gear knob to change the operation of the gear shifter to push down
Small spacers were installed to the sun-visors to assist with operation. The car was lowered 50mm  and the right side of the drivers seat cushion was de bolstered to make for an easier transfer.

The windows were tinted, a key paddle was fabricated,
– Soften operation of exterior door handle so Hillary is able to open the door
– De bolster right side of seat cushion for easier transfer and lower seat height handle
– Fabricate custom control knobs for heater controls, headlight switch and rear wiper to enable Hillary to engage her finger to operate
– Fabricate extension knobs for window switches on left and right sides
– Fabricate key extension
– Tint windows with darkest legal tint

Options

• Mechanical Push Pat hand controls
• Flip up accelerator with left foot plate
• Assorted custom made billet aluminium adaptions
• Modified seat and suspension
• Fabricated key extension
